Tigerrig exquisite alloy steel reliable sealing performance stud type integral joint

< >

Features
Specification

Tigerrig exquisite alloy steel reliable sealing performance stud type integral joint

Production Description：

I plant production of bolted integral joint, mainly for the assembly and connection of high pressure manifold.Manufactured in strict accordance with API Spec6A specification.All are alloy steel forging rough machining, sealing groove adopts numerical control machine machining, sealing performance is reliable., 21/16 ~ 51/8 °, the specification, the rated working pressure of 35 mpa to 105 mpa (5000 psi - 20000 ps1) integral two-way, tee, four-way, five-way, etc., can provide the normal temperature, low temperature and sulfurous gas containing hydrogen sulfide and other circumstances under the conditions of using various models.All kinds of products are available. The specifications and sizes of each connecting end can be customized for users.

Stud type integral joint.jpg

Specifications

Model	Connection	Pressure
sWG70-35-52Z	21/16"-5000 psi API	35 MP
sWG70-70-52Z	21/16-10004	70MPa
SWG70-105-52Z	21/16°-1600001	105MPa
sWG70-35-65Z	29/16°-5000psAP	35 MPa
SWG70-70-65Z	29/167-10000AP	70 MP
sWG70-105-65z	29/16-10000AP	105 MPa
SWG70-35-80Z	31/8"-5000psAP	35 MP
SWG70-70-78z	31/16”-10000psAP	70 MPa
swG70-105-78Z	31/16°”-15000psAP	105 MPa
sWG70-35-103Z	41/16”-5000psAP	35 MPa
sWG70-70-103	41/16″-10000psi API	70 MPa
sWG70-105-103z	41/16″-15000psi API	105Ma
