Tigerrig operation high and low pressure composite manifold
Production Description：
Combination of high and low pressure manifold is according to the requirements of the fracturing operation process, will be after sand fracturing fluid after car or liquor mix to the low pressure manifold, again by fracturing truck (or forced) inhalation, formation pressure, through high pressure remit to gather, high and low pressure combination's remit is to low pressure gathering. Low voltage shunt and high-pressure collection integrating manifold, and meet the requirement of field use, saved the space used by manifold space, realize the fast moving fast loading.
Main technical parameters
Partial pressure of high pressure :42MPB~140MPa
Nominal diameter of low pressure part :8-12
Nominal diameter of high pressure part :2~3
