Tigerrig fracturing wellhead device/API 6A Wellhead & Christmas Tree for Oil and Gas Well

< >

Features
Specification

Tigerrig fracturing wellhead device/API 6A Wellhead & Christmas Tree for Oil and Gas Well

Production Description：

Fracturing tree is an important part of fracturing equipment, mainly composed of multiple fracturing gate valves and fracturing heads. Fracturing media is input from multiple fracturing cyanides to the fracturing head, through the fracturing gate valve, and into the bottom fracturing rock formation. The maximum diameter of the fracturing tree produced by our company is 180MM, and the maximum working pressure is 140MPA.

Tigerrig Fracturing tree.jpg

Specifications

Nominal diameter	Working pressure	Connection method		Operation type
5 1/8	35	Flange connection	bolt	Manual & hydraulic
	70
	105
7 1/16	140

Material level	application	Body, cover, end and outlet connections	Pressure parts, valve stem and mandrel hanger
AA	General use	Carbon steel or low alloy steel	Carbon steel or low alloy steel
BB	General use	Carbon steel or low alloy steel	stainless steel
CC	General use	stainless steel	stainless steel
DD	General use	Carbon steel or low alloy steel	Carbon steel or low alloy steel
EE	Acidic environment	Carbon steel or low alloy steel	stainless steel
FF	Acidic environment	stainless steel	stainless steel
HH	Acidic environment	Corrosion resistant alloy	Corrosion resistant gold
