Tigerrig high quality and best price Hydraulic control cabinet for oilfield
Production Description：
The control box is installed on the drill floor, which can control the hydraulic throttle valve on the remote (remote) manifold. The control box panel is equipped with a vertical pressure gauge, a sleeve pressure gauge, a valve position opening gauge, an oil pressure gauge, and an air pressure gauge.
Three-position four-way directional valve. The air source of the control box comes from the air control system of the drilling rig. The oil pressure gauge displays the system oil pressure value. The three-way four-way valve can be used to control the opening and closing of the hydraulic throttle valve remotely (remotely). The opening degree, thereby controlling the decrease, increase, and stability of the closing pressure and the vertical pressure.
The vertical pressure gauge displays the shut-in riser pressure, and the casing pressure gauge displays the shut-in casing pressure. The pneumatic valve position transmitter is installed at the end of the hydraulic throttle valve cylinder. The input air pressure is 0.35MPa, and the output air pressure returns to the valve position display on the control box to show the opening degree of the valve.
