Gamboss EXDIIBT4/IECEX/A-TEX Ex-Proof Motor Drive 320/272/200 m3/h capacity Weighted Drilling Fluid Jet Mud Mixer Device

< >

Features
Specification

Gamboss EXDIIBT4/IECEX/A-TEX Ex-Proof Motor Drive 320/272/200 m3/h capacity Weighted Drilling Fluid Jet Mud Mixer Device

Product Description：

Jet Mud Mixer consists of one centrifugal pump, one feeding hopper and one jet mixer. Generally, there are still pipes and valves connecting all these parts, the mud hopper matched on the jet mud mixer always 4“and 6”. Jet Mud Mixer could be installed on a skid to be a separate unit; sometimes the jet mud mixer is installed on the mixing tank and could be transported together with mud tank. When the Jet Mud Mixer is independently installed on the skid, a control panel could be offered together for easy operation

1. Mechanical seal mixing pump

2. Venturi type mud hopper

3. Double hopper and pump design available

4. Installation flexible on

Gamboss mud mixer device.jpg

Specifications

Model	SLS45A-750	SLS45A-550	SLS35A-450	SLS35A-370	SLS35A-300	SLM25A-220	SLM25A-185	SLM20A-150	SLM20A-110
Capacity(m3/h)	320(1408 GPM)	272(1200 GPM)	200(880 GPM)	150(660 GPM)	120(528 GPM)	90(400 GPM)	65(286 GPM)	55(242 GPM)	45(200 GPM)
Motor(kw	75(100hp)	55(75hp)	45(60hp)	37(50hp)	30(40hp)	22(30hp)	18.5(25hp	15(20hp)	11(15hp)
Inlet（in）	8	8	6	6	5	5	4	4	4
Outlet(in)	6	6	6	6	6	4	4	4	4
Standard	EXDIIBT4/IECEX/A-TEX
Pressure	0.25~0.4Mpa
Weight /kg	1785	1675	1475	1460	1380	1167	1147	970	950
Size (mm)	220×18 40×1150	2200×18 40×1100	2200×18 40×1135	2200×18 40×1135	1850×15 40×1100	1850×15 40×1000	1850×15 40×1030	1850×15 40×1030	1850×15 40×1030
