Tigerrig GA GAT Series Rubber Sealed Bit With Roller Bearing
Production Description:
GA/GAT series bit adopts rubber seal with roller bearing, which is the ideal and economical tool for drilling applications where middle to low WOB and high RPM are required.
1.The size range of HGA/GAT series bit is 12 1/4 - 17 1/2 inch and its IADC code is 114 – 545.
Main structure features:
2.Sealed roller bearing structure. With rollers arranged in grooves recessed in the cone body, the size of the bearing journal is increased, therefore, with the ability of enduring high WOB and applying for high RPM.
3.Thrust bearing surfaces are hardfaced and treated with friction reducing technology.
4.All rubber compensators are used which can limit pressure differential and prevent drilling fluid from entering the lubrication system and this provides the bearing system with good assurance of lubrication.
Specifications
Bit size
Bit Type
in
mm
12 1/4
311.2
GA114G GAT115 GA124 GA135G GAT215G GA415G GA425 GA535G GA545GY
13 1/2
342.9
GA114 GA115G GA135 GAT415 GAT535G
13 3/4
349.3
GA114 GA115G GAT115G GAT125G GAT415G GAT43G GA515G GAT515G
14 3/4
374.7
GA114G GA115G GAT115 GA124 GAT125G GAT435GC GAT515G GA535G GA545C
16
406.4
GA114 GA115 GAT115 GA134G GAT415GC GAT453G GA515G GAT535G
17 1/2
444.5
GA114G GA115G GAT115 GAT125G GA135G GA215G GAT415G GAT435G GAT445G GAT515G GA525G GAT535G GA545GY
