Tigerrig JOY HCS series Hinged Casing Spider for Oil well repairing tools
Production Description:
Pneumatic chucks are mainly used for the holding of tubing, drill pipe, casing and other pipe columns in oil field drilling and workover operations. The special section of the valve design allows the electric submersible pump cable to pass through the tubing string at the same time. The product is designed and manufactured according to API Spec 7K specifications.
Specifications
Model
Applicable diameter of tubular (in)
Taper
Rated Capacity (Short tons)
JOY133/8/200
7-8.5/8
1:3
200
9-13.3/8
1:4
JOY20/200
9-20
JOY30/200
16-30
JOY36/200
18.5/8-36
JOY30/500
500
JOY36/500
HCS20/500
2.3/8-20
