Tigerrig high pressure exquisite the annular manifold
Production Description：
The annular manifold is applicable to all kinds of oil field high-pressure operation discharge pipelines, infusion pipelines, well test pipelines, cementing mud pipelines and other high-pressure conditions transport fluid flow. It is composed of movable elbow, straight tube assembly, easy to stack, convenient transportation and storage. Flexible, anti - shock, anti - shock, high flow characteristics. There are mainly three types of annular manifold: short radius annular manifold, long radius annular manifold and flexible annular manifold. Specifications have 1 ∵, 1-1/2, 34 ", the pressure of work 35 mpa - 140 mpa (500-200 (p5). The activity type elbow general.
Specifications
Purchasing no.
Work stress
Connecting format
Developed length （m）
Behavior in service
K05100800001
SMG05-42-1D
42MPa
1”FIG602
3
standard
K05150800001
SMG05-42-11/2D
11/2”FIG602
K05200800005
SMG05-42-2D
2”FIG602
