Gamboss European union standard IECEX LSB100 2*3J series Vertical sand pump for ZJ70DBS Drilling Rig
Product Description：
LSB serial vertical pump is a feeding pump designed and manufactured according to special requirements of installation. The LSB Vertical pumps are applicable to deliver corrosive drilling fluid (with suspended particulates) or other liquid media under similar work condition. It is mainly used in limited area and as feed pump of centrifuge. We have 9 modes of LSB100 and LSB2x3 which are suitable for power grids of 50Hz and 60Hz.\
No Leakage: vertical pumps use combined seal relying mainly on mechanical seal and packing subsidiary, the mechanical seal is designed by us with patent ZL20072 007957.2. The service life is 6 times as normal mechanical seal.
High Efficiency: Impeller and case have a streamlined design.
Long service life: The flow parts of vertical pumps are made of high wearable cast iron.
No Jam: The impeller has wide flow pass.
Small Area: Vertical structure.
Specifications
Model
Flow（m3/h）
Head（m）
Speed（rpm）
Efficiency（%）
Power（kw）
Weight/kg
Size/mm
50HZ
60HZ
Shaft power
Motor power
LSB100-45
200
22
1480
1780
58
20.7
45
850
2236×845×815
LSB100-37
160
18
13.5
37
835
2211×845×815
LSB100-30
15
1470
11.3
30
750
LSB100-22
150
10.6
657
2176×845×795
LSB2×3J-11
70
1460
1760
64
5.4
11
305
2238×830×550
LSB2×3J-7.5
60
1440
1750
63
3.9
7.5
243
2104×767×471
LSB2×3J-5.5
50
12.5
62
2.8
5.5
228
2083×767×471
LSB2×3J-4
8
1.8
4
206
2028×717×471
