Gamboss EXDIIBT4/IECEX Ex-Proof Motor Drive 30/40/60/80/110/120 Processing Capacity Alloy Cast Iron Submersible Slurry Pump

< >

Features
Specification

Gamboss EXDIIBT4/IECEX Ex-Proof Motor Drive 30/40/60/80/110/120 Processing Capacity Alloy Cast Iron Submersible Slurry Pump

Product information:

YZ type slag-slurry pump is a vertical single-stage single-suction cantilever centrifugal pump structure, the impeller is a semi-open impeller, in the impeller suction edge extension is provided with a stirring blade. YZ type slurry pump is the main characteristics of the pump shaft in the liquid parts, there is enough stiffness, impeller, pump housing between the bearing, not using shaft seal, can transport the medium containing a large concentration of solid particles; Maintenance-free and high temperature resistant. The length of the pump below insertion is between 800-1900mm, and the suction pipe can be attached if necessary. The drive is mounted on the motor seat by a vertical motor and connected to the pump by a coupling. From the motor direction, the pump clockwise rotation.

Gamboss Submersible Slurry Pump (1).jpg

Gamboss Submersible Slurry Pump (2).jpg

Gamboss Submersible Slurry Pump (3).jpg

Gamboss Submersible Slurry Pump (4).JPG

Gamboss Submersible Slurry Pump (5).JPG

Gamboss Submersible Slurry Pump (6).jpg

Gamboss Submersible Slurry Pump (7).jpg

Gamboss Submersible Slurry Pump (8).jpg

Specifications

Model	50YZ 20A-18	50YZ 40A-10	80YZ 50A-20	80YZ 80A-20	100YZ 100A-30A	100YZ 100A-30	100YZ 160A-38B	150YZ 250A-40B	150YZ 250A-0A
Capacity (m3/h)	30	40	60	80	110	120	164	240	270
Head(m)	10	10	18	20	24	28	26	24	30
Motor(kw)	4	5.5	7.5	11	18.5	22	30	37	45
Motor speed(rpm/50hz)	1450	1450	1450	1450	1450	1450	1450	1450	1450
Motor speed(rpm/60hz)	1750	1750	1750	1750	1750	1750	1750	1750	1750
Outlet size	DN50	DN50	DN80	DN80	DN100	DN100	DN100	DN150	DN150
Standard	EXDIIBt4/IECEX/A-TEX
Weight(kg)	370	600	610	718	840	880	1300	1420	1510
Size(mm)	2620 ×500 ×720	2700 ×500 ×700	2650 ×500 ×700	2750 ×580 ×730	2900 ×600 ×900	2950 ×600 ×900	3100 ×750 ×900	3160 ×700 ×1130	3190 ×700 ×1130
