Gamboss Drill Pipe Drill Collar Drill Bit Casing Fast Safe Time-Saving Labor-Saving V-Type Drilling Tool Transporting Device
Purposes and scope of application
Drilling tool-transporting device mainly used to transport use in well drilling operation with its drilling pipe, drilling collar, drilling bit, casing pipe and other during slim members between fore field and drilling table-board. In operation, pipe-like material rolled into supporting arm V-type transportation groove. Slip shoe fixed inside supporting arm bracket pushes work-pieces to move in rectilinear motion to well mouth in the V-type groove to support the drilling tool where the slip shoe functions to pull as well stop the drilling tool. Then start the hydraulic, which fixed on ramp back and the supporting arm will lift the drilling tool to near well mouth and then the drilling tool is to be lift to well mouth by a lifting tool. Drilling pipe, collar, bit, casing pipe and other slim members taken down will put into supporting arm V-type transportation groove. Then they will be pushes out of the supporting arm V-type transportation groove to fore field material bracket to finish drilling tool transportation by adjustment supporting legs.
Specifications
Gross power of electrical equipment
60KW
Power source
380V/50Hz
Rated displacement (Main parameters)
206L/min
Rated pressure (Main parameters)
35 Mpa
Motor power (Main parameters)
55KW
Cooling mode
Solitary wind cooling
Control mode
Controller + PLC + Sensor
Maximum remote-control radius
Over 100M
Maximum lifting work-piece mass
5000KG
Maximum lifting work-piece length
14.5M
Maximum lifting work-piece diameter
Φ400mm
External dimensions (in folded state)
Length×Width×Height(mm) =19000×3200×2700
Gross weight
25t (including hydraulic oil)
