Gamboss Prefabricated Modular Container Oilfield Easy To Move on Camp House
Product Description：
Jet Mud Mixer consists of one centrifugal pump, one feeding hopper and one jet mixer. Generally, there are still pipes and valves connecting all these parts, the mud hopper matched on the jet mud mixer always 4“and 6”. Jet Mud Mixer could be installed on a skid to be a separate unit; sometimes the jet mud mixer is installed on the mixing tank and could be transported together with mud tank. When the Jet Mud Mixer is independently installed on the skid, a control panel could be offered together for easy operation
1. Mechanical seal mixing pump
2. Venturi type mud hopper
3. Double hopper and pump design available
4. Installation flexible on.
Specifications
Model
SLS45
A-750
A-550
SLS35
A-450
A-370
A-300
SLM25
A-220
A-185
SLM20
A-150
A-110
Capacity(m3/h)
320
(1408GPM)
272
(1200GPM)
200
(880GPM)
150
(660GPM)
120
(528GPM)
90
(400GPM)
65
(286GPM)
55
(242GPM)
45
(200GPM)
Motor(kw
75(100hp)
55(75hp)
45(60hp)
37(50hp)
30(40hp)
22(30hp)
18.5(25hp
15(20hp)
11(15hp)
Inlet（in）
8
6
5
4
Outlet(in)
Standard
EXDIIBT4/IECEX/A-TEX
Pressure
0.25~0.4Mpa
Weight /kg
1785
1675
1475
1460
1380
1167
1147
970
950
Size (mm)
220×18
40×1150
2200×18
40×1100
40×1135
1850×15
40×1000
40×1030
