Tigerrig reliable performance ZQ203-125,ZQ203-100 drill pipe power tong for wellhead handing equipment
Production Description:
The drill pipe power tong is an ideal oil drilling wellhead tool, which is widely used for loading and unloading pipe threading operations in marine, land drilling and workover operations. The use of this clamp can play a role in safety, labor saving and ergonomics. The series of clamps are open type, which can freely disengage the column and have strong maneuverability. The torque clamp and the rotary clamp are integrated into one body, and the upper shackle replaces the cat head, the clamp and the rotary rope. The power tongs are compliant with the SY/T5074 standard.
Specifications
Model
ZQ203-125
ZQ162-5011
ZQ203-10011
ZQ-100111
ZQ203-12511
ZQ203-125111
Applicable pipe diameter
mm
127-203
85-162
in
Maximum torque
KN.m
125
50
100
Ft. lbf
92200
36880
73750
High grade speed
Rpm
40
60
Low gear speed
2.7
4.1
working pressure
Mpa
20
16
16.6
Psi
2900
2320
2400
Hydraulic system rated flow
L/min
114
120
Gpm
30
31.7
Hydraulic system rated pressure
0.5-1
72-144
Transfer cylinder transfer distance
Mm
1500
1000
59
39.4
Power tong walking distance
0-2000
0-3000
0-78.5
0-118
