Gamboss Reliable Performance Oil Well Drilling Mud Decanter Centrifuge Separator of Solid Control Equipment
Main Characteristics:
The superiority of Decanting Centrifuge is embodied in the solids processing size. Decanter Centrifuge could remove the solid particles with size 2-7 microns using the principle of centrifugal action, it is an ideal choice for separating particles in drilling mud. Always there is a screw pump or submersible pump to feed the mud to Decanter Centrifuge. After the drilling fluids being fed into the centrifuge drum, under the function of centrifugal force, solid phase particles are pushed to the internal wall of the drum, then to the solid discharge export of the small end of the drum and excreted. While the fluids is excreted from the overflow hole of the large end. Such cycle is to achieve the purpose of continuous separation. High-speed decanting centrifuge are more effective for separation of fine solids.
Specifications
Model
LW355*1250-N
LW450*1200D
LW450*1250BP-N
LW550*1100BP-N
Driving Mode
VFD
Mech fixed speed
Drum Size (mm)
355*1250
450*1200
450*1250
550*100
Drum Rate Speed (rpm)
0~3200
2200
0~2950
0~1800
Separation Point (um)
2~5
5~7
Max Capacity (m3/h)
40
60
Max G-Force
2100
1218
2189
996
Main Motor(kw)
30
37
45
Differential Torque (N.m)
3500
Differential Speed Ratio
45:1
57:1
39:1
Major motor power (kw)
Auxiliary Motor Power (kw)
7.5
11
Matching Screw Pump (kw/hp)
7.5/11
15/20
Dimension (mm)
2900×1820×1820
2900×1785×1835
2900×1850×1835
Weight (kg)
3100
3300
