Gamboss Export to Russia High Quality Long Work Life CD930 Vertical Cutting Dryer

< >

Features
Specification

Gamboss Export to Russia High Quality Long Work Life CD930 Vertical Cutting Dryer

Product information:

The flights are made from hard high chrome alloy material to be anti-abrasive from solids and ensure long operational life vertical cuttings dryer.

Air Knife is Provided for cleaning the screen to avoid screen blinding.

Balance testing for all major rotary components to minimize vibration & noisy.

Individual oil lubrication system with automatic alarm for pressure limit.

Screw conveyor installed under the dryer to pick up the dry solids for continues operation.

Cleaning pump provided for avoiding solids accumulation in the cuttings dryer.

Gamboss Vertical Cutting Dryer (4).jpg

Gamboss Vertical Cutting Dryer (6).jpg

Gamboss Vertical Cutting Dryer (7).jpg

Specifications

Model	CD930E-GP	CD930E-VFD
Capacity	30~50 Tons/H	30~50 Tons/H
Drying Efficiency	OOC ≤ 5%	OOC ≤ 5%
Screen Max Diameter	930mm	930mm
Screen Opening	0.25/0.35/0.5mm	0.25/0.35/0.5mm
Rotation Speed	900RPM	0-900RPM
G Force	420 or 750 G	420 or 750 G
Oil Tank Capacity	48L	48L
Air Knife Input Pressure	0.69Mpa	0.69Mpa
Air Knife Input Capacity	1.8m3/m	1.8m3/m
Flushing Pump Qty	1pcs	1pcs
Main Motor	55Kw (75HP)	55Kw (75HP)
Oil Pump	0.55Kw(0.75HP)	0.55Kw(0.75HP)
Flushing Pump Power	4Kw(5.5HP)	4Kw(5.5HP)
Ex Standard	ExdIIBt4 / IEC EX/ ATEX	ExdIIBt4 / IEC EX/ ATEX
Electric Cabinet	Exd	Positive Pressurized
Weight	4600Kg	4400Kg
Dimension	2640×1810×1650mm	2640×1810×1650mm
